1.00mm 0.039'' Pitch Square Pin PCB Header Connector with Long-lasting Copper Alloy Contact Material

Product Description:

The Durable 20 Pin PCB Header Connector is a high-quality board to board connector designed for various applications in electronics and electrical systems. This product features a 1.0AMP current rating, making it suitable for low to medium power requirements. The contact material used in this connector is Copper Alloy, known for its excellent conductivity and durability.

Constructed with insulation material PA6T UL 94-V0, this PCB header connector offers reliable performance and safety in diverse operating conditions. The PA6T material is flame retardant and can withstand high temperatures, ensuring the longevity and stability of the connector.

With a withstand voltage of 500V AC/DC, this connector provides effective insulation and protection against electrical breakdown, enhancing the overall safety of the connected devices. The dual row male pin header design of this product allows for secure and stable connections between PCB boards, ensuring reliable signal transmission and power delivery.

The Durable 20 Pin PCB Header Connector is a versatile component that can be used in custom PCB board designs, offering flexibility and customization options for various electronic projects. Whether used as a board to board connector or a female header connector, this product provides a reliable and durable solution for connecting different PCB boards in electronic systems.

Features:

• Product Name: PCB Header Connector
• Termination: Solder
• Contact Resistance: 20mΩ Max
• Pin Available: 2 Pins to 40 Pins
• Contact Material: Copper Alloy
• Contact Shape: Square Pin

Technical Parameters:

Applications:

The JWY ST127-XXXXXX PCB Header Connector is a heavy-duty rectangular connector designed for use in various product applications and scenarios. This product is ideal for connecting circuit boards and wires in custom PCB boards, providing a reliable and secure connection.

Manufactured in China, the JWY PCB Header Connector is certified with UL, SGS, RoHs, and REACH certifications, ensuring high quality and compliance with industry standards. With a minimum order quantity of 2Kpcs, the price is negotiable, and payment terms include T/T and Western Union.

With a supply ability of 100,000pcs per day, the delivery time for the JWY PCB Header Connector is 7 to 15 working days. The packaging details include PE/Tray/Tube/Tape/Reel packaging, offering convenience and protection during transportation.

The JWY ST127-XXXXXX PCB Header Connector is designed to withstand voltage up to 500V AC/DC, with an insulation resistance of 1000MΩ Min. The mounting type is SMD/SMT, suitable for various PCB board designs. The operating temperature range is from -40℃ to +105℃, making it suitable for a wide range of environmental conditions.

With contact finish of Gold Over Nickel, the JWY PCB Header Connector provides a reliable and durable connection for your custom PCB board projects. Whether in industrial applications or electronic devices, this connector is a versatile solution for your connectivity needs.

Support and Services:

The Product Technical Support and Services for the PCB Header Connector product include:

- Assistance with product installation and configuration

- Troubleshooting guidance for any product issues

- Product warranty information and support

- Recommendations for compatible accessories and components

Packing and Shipping:

Product Packaging for PCB Header Connector:

This PCB header connector is carefully packaged in a protective plastic tray to prevent damage during shipping and handling.

Shipping Information:

Orders for the PCB header connector are shipped within 1-2 business days of payment receipt. The product is securely packed in a cardboard box to ensure safe delivery to your location. Shipping times may vary depending on the destination.

FAQ:

Q: What is the brand name of the PCB Header Connector?

A: The brand name of the PCB Header Connector is JWY.

Q: What is the model number of the PCB Header Connector?

A: The model number of the PCB Header Connector is ST127-XXXXXX.

Q: What certifications does the PCB Header Connector have?

A: The PCB Header Connector is certified by UL, SGS, RoHs, and REACH.

Q: What is the minimum order quantity for the PCB Header Connector?

A: The minimum order quantity for the PCB Header Connector is 2,000 pieces.

Q: What are the accepted payment terms for the PCB Header Connector?

A: The accepted payment terms for the PCB Header Connector are T/T and Western Union.
